FactoryCat 34 Walk-Behind Sweeper
Factory Cat’s Floor Sweepers are built to sweep factories: dirt, dust, metal shavings, foundry sand, bolts, paper, wood, etc. Factory Cat’s Sweepers are compact, never light-duty.
The Factory Cat model 34 Walk Behind Sweeper is the machine that built our company. The Factory Cat 34 is an Industrial Sweeper famous for its ability to survive decades in the harshest applications: including mines, brick manufacturing, and rugged steel mills.
Designed almost 25 years ago, this floor sweeper can sweep through the thickest sawdust found in furniture manufacturing plants and the dust in paper mills. Bulk powder packaging clients with concrete powders or copier toners depend on its remarkable sweeping power and its excellent dust control.
The Factory Cat 34 uses all-steel construction, oversized components, and stainless steel fasteners. The oversized motors mean that this machine never struggles and that extra power means a longer life.
Your operators will love the zero-point turning radius and easy maintenance with no oil to change, brooms to reverse, fuel to spill, tanks to exchange, or valves to grind. Just plug it in after every shift.
Used equipment availability changes frequently. Contact us to confirm inventory.
| Specification | FactoryCat 34 |
|---|---|
| Machine Dimensions | |
| Length × Width × Height | 58″ × 31″ × 38″ |
| Weight Without Batteries | 320 lbs |
| Weight With 245 Ah Batteries | 450 lbs |
| Weight With 325 Ah Batteries | N/A |
| Frame Construction | 1/8″ steel |
| Front Drive Wheel (Diameter × Width) | 6″ × 2″ |
| Rear Wheels (Diameter × Width) | (2) 10″ × 1.75″ |
| Sweeping System | |
| Sweeping Method | Direct throw |
| Main Broom (Length × Diameter) | 26″ × 10″ |
| Main Broom Power/Speed | 1.0 hp / 400 rpm |
| Side Broom Size | (1) 17″ |
| Side Broom Power | (1) 0.3 hp |
| Side Broom Speed | 65 rpm |
| Hopper Capacity | 2.0 cu. ft. / 56 liters |
| Battery System | |
| Battery Run Time | 3–5 hours |
| Charger | 25 amp, 110–160 Hz automatic |
| Filtering Material | |
| Filter Material | Polymer felt |
| Filter Rating | 1 micron |
| Filter Size | 5,182 sq. in. |
| Vacuum Rating | 250 cfm |
| Drive System | |
| Drive Power | 1.0 hp |
| Speed Control | 0–3 mph |
| Productivity | |
| Cleaning Width | 34″ |
| Cleaning Rate | 30,000 sq. ft./hr. |
| General | |
| Sound Level | 70 dBA |
