FactoryCat MICROMAG Walk-Behind Scrubber

Factory Cat’s MICROMAG Walk Behind Floor Scrubber was designed based on the already well-known Factory Cat MAGNUM and MINIMAG.

The goal with the MICROMAG Floor Scrubber is to have the smallest Walk Behind Floor Scrubber available without sacrificing solution tank space or productivity in terms of scrubbing performance.

Factory Cat’s MICROMAG comes equipped with either a Brush-Assist drive which allows for operator ease with little-to-no pushing or a Traction drive which includes a powerful all-gear transaxle for climbing ramps and maximum operator ease. The Brush-Assist drive is great for level surfaces and for a cheaper option in comparison to the Traction. The Traction drive offers unparalleled performance when climbing steep ramps and working on non-level surfaces.

Used equipment availability changes frequently. Contact us to confirm inventory.

Technical Specifications	FactoryCat MicroMag
Length	35 in
Width	18 in
Height	38 in
Weight without Batteries	110–160 lbs
Weight with Batteries	290–340 lbs
Chassis Construction	1/8-in powder-coated steel
Front Wheels	Two 2.5 × 1.38 in non-marking wheels
Rear Wheels	Two 8 × 2 in non-marking wheels
Disc Options	One 17-in or one 20-in disc
Disc Motor	0.75 hp / 559 W
Disc Brush Speed	200 rpm
Maximum Brush Down Pressure	100 lbs
Actuator Rating	500 lbs
System Voltage	24 VDC
Standard Battery	85 Ah wet
Optional Battery	Up to 130 Ah wet or 115 Ah AGM
Charger	Onboard
Runtime	Up to 2 hours
Drive System	Pad assist
Maximum Forward Speed	2.6 mph
Maximum Scrubbing Speed	2 mph
Maximum Reverse Speed	1.5 mph
Solution Tank Capacity	10 gal
Recovery Tank Capacity	10 gal
Solution Flow	0–0.5 gpm
Demisting Chamber Capacity	1.25 gal
Drain Saver Capacity	30 in³
Vacuum Motor	0.8 hp, three-stage / 640 W
Vacuum Water Lift	70 in
Vacuum Airflow	70 cfm
Theoretical Productivity	Up to 15,748 ft²/hr
Practical Productivity	Up to 7,308 ft²/hr
