FactoryCat TR v2.0 Rider Sweeper

Factory Cat’s Floor Sweepers are built to sweep factories: dirt, dust, metal shavings, foundry sand, bolts, paper, wood, etc.

The Factory Cat model TR v2.0 design was built from the success of our Model 34 walk behind sweeper. The TR’s side brooms sweep up dirt in the corners while a huge tubular sweeping broom under the machine sweeps up the dirt and debris from the floor and packs it into the steel hopper.

The second stage vacuums up the dust and traps it in a polypropylene felt “baghouse” filter. Factory Cat’s Industrial floor sweepers can pick up whole bags of cement at a time without leaving a trace of dust behind.

Your operators will love the zero-point turning radius and easy maintenance with no oil to change, brooms to reverse, fuel to spill, tanks to exchange, or valves to grind. Just plug it in after every shift.

Used equipment availability changes frequently. Contact us to confirm inventory.

Specification	FactoryCat TR v2.0
Machine Dimensions
Length × Width × Height	64″ × 37″ × 50″
Weight With Standard Batteries	1,115–1,165 lbs
Chassis Construction	3/16″ steel, powder coated
Front Wheel (Diameter × Width)	10″ × 5″
Optional Front Wheel	12″ × 4″
Rear Wheels (Diameter × Width)	(2) 14″ × 5″
Sweeping System
Main Broom (Diameter × Length)	11″ × 32″
Broom Power/Speed	1.0 hp / 435 rpm
Side Broom Size	(2) 19″
Hopper Capacity	4.2 cu. ft. / 116 liters
Power System
System Power	24 VDC / 240 Ah
Optional Battery	Up to 420 Ah wet / 390 Ah AGM
Run Time	Up to 5 hours
Drive System
Power	1.0 hp, all gear/sealed
Speed Control	0–308 ft/min / 0–3.5 mph
Filtering System
Filtering Material	Polymer felt/baghouse
Filter Rating	1 micron
Filter Size	5,192 sq. in.
Vacuum Airflow	280 cfm
General
Cleaning Width	48″
Sound Level	65 dB
Productivity – Theoretical	Up to 75,000 sq. ft./hr.
Productivity – Practical	Up to 59,406 sq. ft./hr.
