PowerBoss Nautilus LD

Simplistic in operation design yet powerful cleaning ability: meet the PowerBoss Nautilus ride-along industrial and commercial floor scrubber. Specially designed to deliver professional cleaning results, the powerful Eaton hydraulic motors provide 200-400 pounds of cleaning pressure that can be used for either scrubbing or polishing. The vacuum completely dries the floor to ensure it’s safe for traffic moving around the facility.

Equipped with easy roll casters on the quick load hopper, debris is easily removed from the machine following cleaning applications. The Safety Dump debris trays work alongside this update to allow the operator to safely dispose of any debris that may be picked up during the application. Constructed of stainless steel to be corrosion resistant, the Nautilus offers operators extended run-time to ensure a complete application.

KEY FEATURES

  • Quick Load Hopper: The squeegee is tilted up out of the way so the debris hopper can be removed from the machine. Now the hopper can be moved effortlessly using the Easy Roll Casters. Now the debris can be disposed of safely and easily using the plastic Safety Dump debris trays.
  • Quick View Squeegee: The squeegee tilts up for squeegee adjustments or changes to be made quickly. This feature also allows for daily inspection and clog removal to be performed easily.
  • Edge Scrub: The optional heavy duty edge scrub allows the operator to clean close to walls and rack rows. If contact is made the assembly collapses underneath the machine momentarily then resumes its normal position. The edge scrub assembly retracts underneath the machine when not in use.
  • Stainless Steel: No Corrosion, Made to Last.

Used equipment availability changes frequently. Contact us to confirm inventory.

SpecificationNautilus
Machine Dimensions
Length × Width × Height95″ × 53″ × 60.5″ at lowest steering-wheel position
Height With Overhead Guard83.5″
Width at Frame55″
Width at Rear Squeegee56″
Width With Side Brush65.5″
Weight – Empty3,250 lbs
Gross Vehicle Weight4,800 lbs
Minimum Aisle Turn107.7″
Integrated Cleaning System
Cleaning Path45″
Cleaning Path With Scrubbing Side Brush60″
Cleaning Path With Sweeping Side Brush62″
Cylindrical Main Brushes
Brush Speed425 rpm
Brush Down PressureUp to 400 lbs
Brush Diameter(2) 12″
Disc Main Brushes
Brush Speed225 rpm
Scrub Brush Diameter(3) 16″
Side Brush
Brush Speed200 rpm
Tanks
Solution Tank Capacity105 gallons
Recovery Tank Capacity105 gallons
Demisting Chamber17 gallons
Debris Hopper
Volume Capacity2.09 cu. ft. / 15.6 gallons
Vacuum Fan
Scrubbing Fan Speed11,500 rpm
Scrubbing Fan Water Lift35″
Propelling System
Gasoline Engine1.5-liter Kubota WG1605G
Gasoline Gross Intermittent Power57 hp / 3,600 rpm
Gasoline Governed Power40.5 hp / 2,400 rpm
LPG Engine1.5-liter Kubota WG1605L
LPG Gross Intermittent Power55 hp / 3,600 rpm
LPG Governed Power39.4 hp / 2,400 rpm
Diesel Engine1.5-liter Kubota V1505
Diesel Gross Intermittent Power24.8 hp / 2,300 rpm
Diesel Governed Power24.8 hp / 2,300 rpm
Performance
Gradeability – Transport at Gross Weight10° / 17.45%
Gradeability – Working/Cleaning8° / 14%
